Angle Brackets

Angle Brackets — also called angle brackets or L-brackets — provide structural reinforcement at 90° connections in curtain wall systems and steel frameworks.

At Fabao Machinery, we supply corner braces in carbon steel (Q235B), stainless steel (304/316), and aluminum alloy, with custom dimensions, hole patterns, and surface treatments available. Hot-dip galvanizing, electro-galvanizing, and powder coating options come standard. Custom orders based on your drawings are welcome.

Get Your Custom Quote

45° Angle Brackets for Curtain Wall & Steel Connections →

  • Angle: 45° (custom 15°, 30°, 60°, 75°, 120° available)
  • Material: Q235B Carbon Steel, Stainless Steel 304/316, Aluminum Alloy 6063-T5
  • Thickness: 2mm – 10mm (varies by material)
  • Leg Length: 40×40 mm up to 200×200 mm (custom sizes available)
  • Surface Finish: Hot-dip galvanized, electro-galvanized, powder coated, anodized (silver/black/bronze)
  • Hole Type: Round, slotted, countersunk, multi-hole patterns
Learn More

90° Angle Brackets in Bulk – High-Precision L-Brackets with Fast Lead Times →

  • Angle: 90° (standard); custom angles for special joints available
  • Material: Q235B Carbon Steel, Stainless Steel 304/316, Aluminum Alloy 6063-T5
  • Thickness: 2mm – 12mm (varies by material and load)
  • Leg Length: 30×30 mm up to 300×300 mm (custom sizes on request)
  • Surface Finish: Hot-dip galvanized, electro-galvanized, powder coated, anodized
  • Hole Type: Plain round, slotted for adjustment, multi-hole patterns per drawing
Learn More

90° Corner Braces for Facade & Steel Frame Assembly →

  • Angle: 90° standard; equal-leg and unequal-leg options available
  • Material: Q235B Carbon Steel, Stainless Steel 304/316, Aluminum 6063-T5
  • Thickness: 2mm – 12mm
  • Leg Length: 25×25 mm up to 300×300 mm; unequal legs on request
  • Surface Finish: Hot-dip galvanized, electro-galvanized, powder coated, anodized
  • Hole Configuration: Pre-drilled round holes, slotted holes for on-site adjustment
Learn More

Aluminum 90° Corner Braces for Curtain Wall & Light Framing →

  • Angle: 90° equal-leg; unequal-leg and reinforced rib designs on request
  • Material: Aluminum Alloy 6063-T5 (standard), 6061-T6 (higher strength)
  • Thickness: 2mm – 6mm (extruded profile)
  • Leg Length: Customization
  • Surface Finish: Anodized (clear/silver), black anodized, bronze anodized, powder coated RAL colors
  • Hole Type: Pre-drilled round holes; slotted for alignment; can be supplied blank for site drilling
Learn More
